JVC UX-G375A

MODEL MARK MODEL MARK MODEL MARK MODEL MARK
UX-G375A A UX-G375B B UX-G375E C UX-G375EN D
UX-G375EV E UX-G375UP F UX-G375US G UX-G375UT H
UX-G375UW I UX-G377E J UX-G377EN K UX-G377EV L
UX-G377UT M UX-G395BE N UX-G395BEN O UX-G395BEY P
UX-G395WE Q UX-G395WEN R UX-G395WEY S
Safe Symbol No. Parts No. Parts Name Description QTY Local
D19 CD1311001040030 DIODE 1311-001040030 1
D19 or CD1311001040010 DIODE 1311-001040010 1 N,O,P,Q,R,S
! C1 CD1111224243870 CAPACITOR 1111-224243870 1
! C1 or CD1111224133790 E CAPACITOR 1111-224133790 1 N,O,P,Q,R,S
! C2 CD1111224243870 CAPACITOR 1111-224243870 1
! C2 or CD1111224133790 E CAPACITOR 1111-224133790 1 N,O,P,Q,R,S
! C3 CD1111152143010 C CAPACITOR 1111-152143010 1
! C3 or CD1111152143001 C CAPACITOR 1111-152143001 1 N,O,P,Q,R,S
! C4 CD1111152143010 C CAPACITOR 1111-152143010 1
! C4 or CD1111152143001 C CAPACITOR 1111-152143001 1 N,O,P,Q,R,S
! C5 CD1112127203300 E CAPACITOR 1112-127203300 1
A,B,C,D,E,F,G,H,I,J,K,L,M
! C5 CD1112127203860 E CAPACITOR 1112-127203860 1 N,O,P,Q,R,S
! C6 CD1111472193001 C CAPACITOR 1111-472193001 1
! C6 or CD1111472193000 C CAPACITOR 1111-472193000 1 N,O,P,Q,R,S
! C7 CD1131471082000 C CAPACITOR 1131-471082000 1
C8 CD1131471082000 C CAPACITOR 1131-471082000 1
C9 CD1132476063060 E CAPACITOR 1132-476063060 1
C10 CD1131104084000 C CAPACITOR 1131-104084000 1
C11 CD1111472193001 C CAPACITOR 1111-472193001 1
C11 or CD1111472193000 C CAPACITOR 1111-472193000 1 N,O,P,Q,R,S
C12 CD1131103084000 C CAPACITOR 1131-103084000 1
C13 CD1112108053160 E CAPACITOR 1112-108053160 1
A,B,C,D,E,F,G,H,I,J,K,L,M
C13 CD1132108053161 E CAPACITOR 1132-108053161 1 N,O,P,Q,R,S
C14 CD1132337053220 E CAPACITOR 1132-337053220 1
C15 CD1132337053220 E CAPACITOR 1132-337053220 1
C16 CD1132337053220 E CAPACITOR 1132-337053220 1
C17 CD1132228073271 E CAPACITOR 1132-228073271 1
A,B,C,D,E,F,G,H,I,J,K,L,M
C17 CD1132228073270 E CAPACITOR 1132-228073270 1 N,O,P,Q,R,S
C18 CD1132477073140 E CAPACITOR 1132-477073140 1
A,B,C,D,E,F,G,H,I,J,K,L,M
C18 CD1132477073150 E CAPACITOR 1132-477073150 1 N,O,P,Q,R,S
C19 CD1132476083100 E CAPACITOR 1132-476083100 1
C20 CD1132105083030 E CAPACITOR 1132-105083030 1
C21 CD1132337053220 E CAPACITOR 1132-337053220 1
C23 CD1112127203300 E CAPACITOR 1112-127203300 1
A,B,C,D,E,F,G,H,I,J,K,L,M
C23 CD1112127203860 E CAPACITOR 1112-127203860 1 N,O,P,Q,R,S
! C24 CD1131102082000 C CAPACITOR 1131-102082000 1
B,C,D,E,J,K,L,N,O,P,Q,R,
S
C25 CD1132107053060 E CAPACITOR 1132-107053060 1
A,B,C,D,E,F,G,H,I,J,K,L,M
C25 CD1132107053063 E CAPACITOR 1132-107053063 1 N,O,P,Q,R,S
C26 CD1131104084000 C CAPACITOR 1131-104084000 1
C27 CD1132226083060 E CAPACITOR 1132-226083060 1
C28 CD1111472193001 C CAPACITOR 1111-472193001 1
C28 or CD1111472193000 C CAPACITOR 1111-472193000 1 N,O,P,Q,R,S
C29 CD1121102102030 C CAPACITOR 1121-102102030 1 A,B,F,G,H,I,M
C32 CD1121102102030 C CAPACITOR 1121-102102030 1 A,B,F,G,H,I,M
C33 CD1121472143120 C CAPACITOR 1121-472143120 1 A,F,G,H,I,M
R1 CD1237105012000 RESISTOR 1237-105012000 1
B,C,D,E,J,K,L,N,O,P,Q,R,
S
R2 CD1237473082000 RESISTOR 1237-473082000 1
R3 CD1237047082000 RESISTOR 1237-047082000 1
R4 CD1231470042000 RESISTOR 1231-470042000 1
R5 CD1231821042000 RESISTOR 1231-821042000 1 A,F
R5 CD1231332022000 RESISTOR 1231-332022000 1
B,C,D,E,G,H,I,J,K,L,M,N,
O,P,Q,R,S
R6 CD1231103032000 RESISTOR 1231-103032000 1
R7 CD1231102042000 RESISTOR 1231-102042000 1
R8 CD1231220022000 RESISTOR 1231-220022000 1
R9 CD1231203042000 RESISTOR 1231-203042000 1
R10 CD1237330082000 RESISTOR 1237-330082000 1
R11 CD1231100042000 RESISTOR 1231-100042000 1
R12 CD1231104041000 RESISTOR 1231-104041000 1
R13 CD1237472012000 RESISTOR 1237-472012000 1
R14 CD1231472042000 RESISTOR 1231-472042000 1
R15 CD1231102042000 RESISTOR 1231-102042000 1
R16 CD1231102042000 RESISTOR 1231-102042000 1
R17 CD1221102062030 CHIP RESISTOR 1221-102062030 1
A,B,C,D,E,F,G,H,I,J,K,L,M
R17 CD1221102042030 RESISTOR 1221-102042030 1 N,O,P,Q,R,S
R18 CD1231101042000 RESISTOR 1231-101042000 1
R19 CD1231102042000 RESISTOR 1231-102042000 1
R20 CD1231332021000 RESISTOR 1231-332021000 1
R21 CD1231362041000 RESISTOR 1231-362041000 1
R22 CD1231472042000 RESISTOR 1231-472042000 1
R23 CD1231101072000 RESISTOR 1231-101072000 1
R24 CD1211100072000 RESISTOR 1211-100072000 1
R25 CD1231273042000 RESISTOR 1231-273042000 1 A,F,G,H,I,M
(No.MB729<Rev.004>)13/
24
