MODEL MARK MODEL MARK MODEL MARK MODEL MARK
UX-G375A A UX-G375B B UX-G375E C UX-G375EN D
UX-G375EV E UX-G375UP F UX-G375US G UX-G375UT H
UX-G375UW I UX-G377E J UX-G377EN K UX-G377EV L
UX-G377UT M UX-G395BE N UX-G395BEN O UX-G395BEY P
UX-G395WE Q UX-G395WEN R UX-G395WEY S
Safe Symbol No. Parts No. Parts Name Description QTY Local
R25 CD1231243042000 RESISTOR 1231-243042000 1
B,C,D,E,J,K,L,N,O,P,Q,R,
S
R26 CD1231184042000 RESISTOR 1231-184042000 1
R27 CD1211222042000 RESISTOR 1211-222042000 1
R28 CD1231331062000 RESISTOR 1231-331062000 1
R29 CD1211222042000 RESISTOR 1211-222042000 1
R30 CD1237220082000 RESISTOR 1237-220082000 1
R31 CD1237220082000 RESISTOR 1237-220082000 1
R32 CD1237105012000 RESISTOR 1237-105012000 1 A,F,G,H,I,M
R33 CD1221220022050 CHIP RESISTOR 1221-220022050 1 A,B,F,G,H,I,M
R34 CD1221220022050 CHIP RESISTOR 1221-220022050 1 A,B,F,G,H,I,M
R36 CD1237105012000 RESISTOR 1237-105012000 1 A,F,G,H,I,M
R37 CD1221101012050 CHIP RESISTOR 1221-101012050 1 A,F,G,H,I,M
! L1 CD2104000000270 LINE FILTER 2104-000000270 1 A,F,G,H,I,M
! L1 CD2104000000130 LINE FILTER 2104-000000130 1
B,C,D,E,J,K,L,N,O,P,Q,R,
S
L2 CD1231560022000 RESISTOR 1231-560022000 1 A,F,G,H,I,M
L2 CD1604102174000 COIL 1604-102174000 1
B,C,D,E,J,K,L,N,O,P,Q,R,
S
L2 or CD1604102140000 INDUCTOR 1604-102140000 1 N,O,P,Q,R,S
L3 CD1614100003010 INDUCTOR 1614-100003010 1
L3 or CD1614100005010 INDUCTOR 1614-100005010 1 N,O,P,Q,R,S
L4 CD1614100006000 POWER INDUCTOR 1614-100006000 1
L4 or CD1614100008010 INDUCTOR 1614-100008010 1 N,O,P,Q,R,S
L5 CD1614100003010 INDUCTOR 1614-100003010 1
L5 or CD1614100005010 INDUCTOR 1614-100005010 1 N,O,P,Q,R,S
L6 CD1604100072000 COIL 1604-100072000 1
L6 or CD1604100072010 INDUCTOR 1604-100072010 1 N,O,P,Q,R,S
L7 CD1608300025000 TOROIDAL COIL 1608-300025000 1
! T1 CD2302285000500 POWER TRANSF 2302-285000500 1
CN1 CD3101250221010 HEADER 3101-250221010 1
CN2 CD3101200921000 HEADER 3101-200921000 1
CN3 CD3101250411000 HEADER 3101-250411000 1
CN4 CD8016000000100 FM ANT CONT PIN 8016-000000100 1 A,B,G
CN5 CD3101200221010 HEADER 3101-200221010 1
CNPIN2 CD3401000000420 PUSH TERMINAL 3401-000000420 1 N,O,P,Q,R,S
F3 CD1214109000000 PTC THERMISTOR 1214-109000000 1 A,B,D,E,G,H,J,K,L
F3 CD2004300008700 RESETTABLE FUSE 2004-300008700 1 I,N,O,P,Q,R,S
GND CD8016000000100 FM ANT CONT PIN 8016-000000100 1 A,B,G
GND CD3401000000420 PUSH TERMINAL 3401-000000420 1 N,O,P,Q,R,S
HS1 CD6600061000200 HEAT SINK A 6600-061000200 1
HS2 CD6600081000600 HEAT SINK 6600-081000600 1
HS2 or CD6600081000400 HEAT SINK 6600-081000400 1 N,O,P,Q,R,S
JP7 CD2105046000000 FERRITE COIL 2105-046000000 1 H,M
SW1 CD3101790221000 CONNECTOR WIRE 3101-790221000 1 G,H,I,M
V1 CD1414005600010 MOS FET 1414-005600010 1 A,B,C,D,E,F,G,H,J,K,L,M
V1 CD1414005600011 TRANSISTOR 1414-005600011 1 I,N,O,P,Q,R,S
V1 or CD1414005600000 MOS FET 1414-005600000 1 N,O,P,Q,R,S
V2 CD1411012750000 TRANSISTOR 1411-012750000 1
V3 CD1412080500000 TRANSISTOR 1412-080500000 1
V3 or CD1412380500000 TRANSISTOR 1412-380500000 1 N,O,P,Q,R,S
V4 CD1412080500000 TRANSISTOR 1412-080500000 1
V4 or CD1412380500000 TRANSISTOR 1412-380500000 1 N,O,P,Q,R,S
V5 CD1411085500000 TRANSISTOR 1411-085500000 1
V5 or CD1411385500000 TRANSISTOR 1411-385500000 1 N,O,P,Q,R,S
V7 CD1412080500000 TRANSISTOR 1412-080500000 1
V7 or CD1412380500000 TRANSISTOR 1412-380500000 1 N,O,P,Q,R,S
VD1 CD1323002400000 Z DIODE 1323-002400000 1
VD2 CD1323000680040 Z DIODE 1323-000680040 1 A,F
Display board <03>
U501 CD1513016315010 IC 1513-016315010 1
CH01 CD1121101082020 C CAPACITOR 1121-101082020 1
CH02 CD1121101082020 C CAPACITOR 1121-101082020 1
CH03 CD1121102082020 C CAPACITOR 1121-102082020 1 A,B,C,D,E,F,G,H,J,K,L,M
CH03 CD1121102082021 C CAPACITOR 1121-102082021 1 I,N,O,P,Q,R,S
CH04 CD1121102082020 C CAPACITOR 1121-102082020 1 A,B,C,D,E,F,G,H,J,K,L,M
CH04 CD1121102082021 C CAPACITOR 1121-102082021 1 I,N,O,P,Q,R,S
CH05 CD8022000000600 PULSE GUARD 8022-000000600 1
A,B,C,D,E,F,G,H,I,J,K,L,M
CH05 CD3601180000000 VARISTOR 3601-180000000 1 N,O,P,Q,R,S
CH05 or CD8022000000600 PULSE GUARD 8022-000000600 1 N,O,P,Q,R,S
CH06 CD8022000000600 PULSE GUARD 8022-000000600 1
A,B,C,D,E,F,G,H,I,J,K,L,M
CH06 CD3601180000000 VARISTOR 3601-180000000 1 N,O,P,Q,R,S
CH06 or CD8022000000600 PULSE GUARD 8022-000000600 1 N,O,P,Q,R,S
CH07 CD8022000000600 PULSE GUARD 8022-000000600 1
A,B,C,D,E,F,G,H,I,J,K,L,M
CH07 CD3601180000000 VARISTOR 3601-180000000 1 N,O,P,Q,R,S
CH07 or CD8022000000600 PULSE GUARD 8022-000000600 1 N,O,P,Q,R,S
CH08 CD8022000000600 PULSE GUARD 8022-000000600 1
A,B,C,D,E,F,G,H,I,J,K,L,M
CH08 CD3601180000000 VARISTOR 3601-180000000 1 N,O,P,Q,R,S
CH08 or CD8022000000600 PULSE GUARD 8022-000000600 1 N,O,P,Q,R,S
CK401 CD1121104082020 C CAPACITOR 1121-104082020 1
(No.MB729<Rev.004>)14/
