Power amplifier board
Block No. [0][2]
DI700 QLF0166-001 FL TUBE
EP801 QNZ0136-001Z EARTH PLATE
FW209 QUM156-11DGZ4-E WIRE
FW700 QUM027-15Z4Z4-E WIRE
FW710 QUM024-06Z4Z4-E WIRE
FW801 QUM153-30DGZ4-E WIRE
FW850 QUM024-30DGZ4-E WIRE
FW851 QUM023-20DGZ4-E WIRE
HS230 GV40620-007A HEAT SINK
HS240 GV40620-007A HEAT SINK
HS270 GV40620-007A HEAT SINK
J401 QNN0572-001 PIN JACK
J403 QNZ0775-001 RGB CONNECTOR
J801 QNS0173-002 HEADPHONE JACK
J802 QNZ0851-001 USB CONNECTOR
J850 QNS0173-002 HEADPHONE JACK
JS750 QSW0857-001 ROTARY SW
K385 QQR0621-001Z COIL
S700 QSW0683-001Z PUSH SW
S701 QSW0683-001Z PUSH SW
S702 QSW0683-001Z PUSH SW
S703 QSW0683-001Z PUSH SW
S751 QSW0683-001Z PUSH SW
S752 QSW0683-001Z PUSH SW
S753 QSW0683-001Z PUSH SW
S754 QSW0683-001Z PUSH SW
S755 QSW0683-001Z PUSH SW
S756 QSW0683-001Z PUSH SW
S757 QSW0683-001Z PUSH SW
S758 QSW0683-001Z PUSH SW
S759 QSW0683-001Z PUSH SW
X310 QAX0711-002Z CRYSTAL 8.000000MHz
 Symbol No. Part No. Part Name Description Local
 IC501 STK432-070 IC
IC600 LC75345M-X IC
Q500 RT1P141C-X DIGI TRANSISTOR
Q501 KTC812T-X IC
Q503 KTA1268/GL/-T TRANSISTOR
Q504 KTA1268/GL/-T TRANSISTOR
Q505 KTC3200/GL/-T TRANSISTOR
Q506 2SC3928A/QR/-X TRANSISTOR
Q507 2SA1530A/QR/-X TRANSISTOR
Q510 RT1P141C-X DIGI TRANSISTOR
Q550 2SC3928A/QR/-X TRANSISTOR
Q561 KTC812T-X IC
Q580 2SC3928A/QR/-X TRANSISTOR
Q581 RT1P141C-X DIGI TRANSISTOR
Q641 2SC3928A/QR/-X TRANSISTOR
Q642 2SC3928A/QR/-X TRANSISTOR
Q650 2SC5938A/B/-X I.M. TRANS
Q651 2SC3928A/QR/-X TRANSISTOR
Q652 RT1P141C-X DIGI TRANSISTOR
Q680 KTA1271/OY/-T TRANSISTOR
Q681 RT1N140C-X DIGI TRANSISTOR
D101 MA111-X SI DIODE
 D500 UDZW9.1B-X Z DIODE
D501 MA111-X SI DIODE
D502 MA111-X SI DIODE
D503 MA111-X SI DIODE
 D504 UDZW9.1B-X Z DIODE
D552 MA111-X SI DIODE
D555 MA111-X SI DIODE
D556 MA111-X SI DIODE
 D580 1N5402M-20 SI DIODE
 D581 1N5402M-20 SI DIODE
 D582 1N5402M-20 SI DIODE
 D583 1N5402M-20 SI DIODE
 Symbol No. Part No. Part Name Description Local
D586 MA111-X SI DIODE
D641 UDZW5.1B-X SB DIODE
D642 MA111-X SI DIODE
D645 MA111-X SI DIODE
D646 MA111-X SI DIODE
D651 MA111-X SI DIODE
D652 MA111-X SI DIODE
 C102 QCZ9133-472 C CAPACITOR 4700pF
C500 NCB31HK-471X C CAPACITOR 470pF 50V K
C501 NCB31HK-471X C CAPACITOR 470pF 50V K
C502 QETN1HM-106Z E CAPACITOR 10uF 50V M
C503 QETN1HM-106Z E CAPACITOR 10uF 50V M
C504 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C505 NDC31HJ-101X C CAPACITOR 100pF 50V J
C506 QETN1HM-106Z E CAPACITOR 10uF 50V M
C507 NDC31HJ-5R0X C CAPACITOR 5pF 50V J
C509 QETN1VM-476Z E CAPACITOR 47uF 35V M
C510 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C511 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C517 QETN1HM-106Z E CAPACITOR 10uF 50V M
C518 NDC31HJ-101X C CAPACITOR 100pF 50V J
C519 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C520 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C521 NDC31HJ-5R0X C CAPACITOR 5pF 50V J
C522 QETN1VM-476Z E CAPACITOR 47uF 35V M
C523 QETN1HM-226Z E CAPACITOR 22uF 50V M
C525 QETN1HM-226Z E CAPACITOR 22uF 50V M
C526 QETN1VM-476Z E CAPACITOR 47uF 35V M
C571 NCB31HK-332X C CAPACITOR 3300pF 50V K
C572 NCB31HK-332X C CAPACITOR 3300pF 50V K
C573 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C574 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C575 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C576 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C577 NCB31HK-332X C CAPACITOR 3300pF 50V K
C578 NCB31HK-332X C CAPACITOR 3300pF 50V K
C580 QFNC2AJ-104Z M CAPACITOR 0.1uF 100V J
C582 QFNC2AJ-104Z M CAPACITOR 0.1uF 100V J
C584 QFNC2AJ-104Z M CAPACITOR 0.1uF 100V J
C585 QETM1HM-338 E CAPACITOR 3300uF 50V M
C586 QETM1HM-338 E CAPACITOR 3300uF 50V M
C601 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C602 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C603 QETN1HM-106Z E CAPACITOR 10uF 50V M
C604 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C605 QETN1CM-107Z E CAPACITOR 100uF 16V M
C608 QFLC1HJ-823Z M CAPACITOR 0.082uF 50V J
C610 QFNC2AJ-104Z M CAPACITOR 0.1uF 100V J
C611 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C612 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C613 QETN1HM-106Z E CAPACITOR 10uF 50V M
C614 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C618 QFLC1HJ-823Z M CAPACITOR 0.082uF 50V J
C620 QFNC2AJ-104Z M CAPACITOR 0.1uF 100V J
C621 QFVF1HJ-274Z MF CAPACITOR 0.27uF 50V J
C622 QFVF1HJ-274Z MF CAPACITOR 0.27uF 50V J
C623 QFLC1HJ-823Z M CAPACITOR 0.082uF 50V J
C624 QTE1H46-226Z E CAPACITOR 22uF 50V
C625 QETN1CM-107Z E CAPACITOR 100uF 16V M
C628 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J
C629 QFNC2AJ-104Z M CAPACITOR 0.1uF 100V J
C631 QFVF1HJ-274Z MF CAPACITOR 0.27uF 50V J
C632 QFVF1HJ-274Z MF CAPACITOR 0.27uF 50V J
C633 QFLC1HJ-823Z M CAPACITOR 0.082uF 50V J
C634 QTE1H46-226Z E CAPACITOR 22uF 50V
C638 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J
C639 QFNC2AJ-104Z M CAPACITOR 0.1uF 100V J
C640 QETN1HM-105Z E CAPACITOR 1uF 50V M
C641 QETN1EM-476Z E CAPACITOR 47uF 25V M
C642 NCB31AK-154X C CAPACITOR 0.15uF 10V K
C643 QETN1HM-106Z E CAPACITOR 10uF 50V M
C649 QETN1HM-105Z E CAPACITOR 1uF 50V M
C650 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C651 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C652 QETN1HM-226Z E CAPACITOR 22uF 50V M
C653 QETN1HM-105Z E CAPACITOR 1uF 50V M
C660 QETN1HM-106Z E CAPACITOR 10uF 50V M
 Symbol No. Part No. Part Name Description Local
