JVC UX-M3R User Manual

– 2 –
Contents
Location of the Buttons and Controls ..................... 3
Front Panel ................................................................ 4
Remote Control ......................................................... 5
Getting Started .......................................................... 6
Unpacking ................................................................. 6
Putting the Batteries into the Remote Control .......... 6
Connections .............................................................. 6
Common Operations ................................................. 8
Turning On or Off the Unit ....................................... 8
Setting the Clock ....................................................... 8
Adjusting the Volume ................................................ 8
Digital Sound Control ............................................... 9
Listening to FM and MW Broadcasts ................... 10
Tuning In a Station .................................................. 10
Presetting Stations ................................................... 10
Tuning In a Preset Station ....................................... 11
Receiving FM Stations with RDS........................... 12
Changing the RDS Information .............................. 12
Searching for Programs by PTY Codes
(PTY Search) ..................................................... 12
Playing Back CDs .................................................... 13
Loading a Disc ........................................................ 13
Basic CD Operations .............................................. 13
Program Play ........................................................... 13
Random Play ........................................................... 14
Repeat Play ............................................................. 14
Introductory Play .................................................... 14
Displaying the Remaining Time during Playback .. 14
Playing Back Tapes ................................................. 15
Loading a Tape ........................................................ 15
Tape Playback ......................................................... 15
Rewind/Fast Forward .............................................. 15
Recording ................................................................. 16
Recording Tapes ...................................................... 16
Using the Timers...................................................... 17
Using Daily Timer .................................................. 17
Timer Recording ..................................................... 17
Using Sleep Timer .................................................. 18
Description of the PTY Codes ................................ 19
Troubleshooting ....................................................... 19
Maintenance ............................................................ 20
Specifications ........................................... Back cover
02_01_20_UXM3R_A_En.p65 02.1.23, 2:02 PM2

JVC UX-M3R Specifications

Amplifier Specifications

output power	24 W (12 W + 12 W) at 8 Ω (MAX.)
output power at THD	20 W (10 W + 10 W) at 8 Ω (10% THD)
audio output level	800 mV/32 Ω
speakers impedance	8 Ω - 16 Ω

Tuner Specifications

FM tuning range	87.50 MHz - 108.00 MHz
MW tuning range	522 kHz - 1 629 kHz

CD Player Specifications

dynamic range	60 dB
signal-to-noise ratio	60 dB
wow and flutter	Unmeasurable

Cassette Deck Specifications

frequency response for normal tape	100 Hz - 10 000 Hz
wow and flutter	0.35% (WRMS)

General Specifications

power requirement	AC 240 V, 50 Hz
power consumption (operation mode)	30 W
power consumption (standby mode)	1.5 W
dimensions	160 mm × 269.5 mm × 300 mm
mass	4.3 kg

Speaker Specifications

speaker unit (woofer)	10.2 cm cone × 1
speaker unit (tweeter)	5.1 cm cone × 1
impedance	8 Ω
dimensions	160 mm × 269.5 mm × 192 mm
mass	2 kg/each
