XV-S40BK/XV-S42SL/XV-S45GD
XV-S30BK/XV-E100SL
1-13
Prior to performing the following procedure, remove
the clamper assembly, the tray, the traverse
mechanism assembly, the elevator and the motor
assembly.
Press the two tabs h inward and pull out the idle
gear.
Remove the screw E attaching the pulley gear
bracket. Slide the pulley gear bracket in the direction
of the arrow and pull out the pulley gear.
Slide the slide cam in the direction of the arrow to
release the two joints i and remove upward.
Remove the middle gear.
1.
2.
3.
4.
Removing the Idle gear / pulley gear /
middle gear / slide cam (See Fig.10 to 12)
Fig.11
Fig.12
Fig.10
Motor assembly
Pulley gear
Pulley gear bracket
Pulley gear bracket
E
Idle gear
Idle gear
Pulley gear
Tads h
Pulley gear
Middle gear
Joint i
Joint i
Slide cam
Slide cam
Middle gear
Loading base
