PARTS DIAGRAMS
BL-KR V1.0
BL-KR V2.0
Mounting Holes
Battery
Enclosure
Rain Sensor (yellow)
Stations (red)
Common (black)
Master Valve (orange)
Common (black)
4 and 6 station models
Common (black)
4 and 6 station models
