Kaadas K9-5W - Explosive View

8
9
12 13
11101
1.Battery cover
2.Back panel screw
3.Battery
4.Back panel
5.Square shaft
6.Front panel screw
7.Mounting plate
8.Mortise
9.Spring
10.M6 connecting screw bolt
11.Front panel
12.Rubber plug
13.M5 connecting screw bolt
2 3 4 6 75
• Explosive view
Understanding the installation of a three-dimensional assembly drawing is beneficial to understand lock structure.
