Face plate
latchbolt
Allen wrench
Face plate
Allen wrench
• Before installation
Check door open direction before installation
• Change the direction of Latchbolt
Right-out open
Left-out open
Right-in open
Left-in open
1.Loosen the screw counterclockwise
with an Allen wrench, then take out
face plate.
3.Install back faceplate and tighten
screws, then work done.
2.Take out latchbolt and rotate
180°, then take back latchbolt.
