• Installation steps
1.Drill bores following the installation template and
then put the mortise into the door and tighten the
four mounting screws.
Install the connecting screw bolt on the front panel, and
put the pressure spring and square shaft in the hole.
Note: According to the thickness of the door, choose the appropriate length of
the square shaft and solenoid.
M6
Connecting
Screw bolt
M6
Connecting
Screw bolt
M5
Screw bolt
Front Panel
Connector
Square Shaft
Spring
To Next Page
