6-pin 140
8402-xx-1010
3402-xx-1010
s
tandard
screw hole
locations
8402-xx-1012
3
402-xx-1012
screw holes “high
and outside” for
Sargent exit
devices
plug & shell
assembly
break-off screws
2 required
backplate
3500-xx-2003 collar
finish to match cylinder
Each 8402/3402 cylinder assembly includes these
components:
4701-98-4118
screws, 2 required
4702-80-2009
rim cylinder tailpiece
3410-00-2001
tailpiece retainer
Conventional Rim Cylinders—8402/3402 Series
