Kaba Peaks Preferred

Section 3 - 6
Key Cutting & Pinning
Pin Lengths and Stack Heights
Pin lengths and material
Kaba bottom pins are .003" shorter than after market replacement pins.
N
on-original pins will not work properly and void the product warranty.
“S” indicates spool type pins. Bottom pins are nickel silver.
Top pins are brass.
top pin
part number length A2 A4
3800-00-4202 .025 2B
-4203 .0375 3B
-4204 .050 4B
-4205 .0625 5B
-4206 .075 6BS
-4207 .0875 7B
-4208 .100 8BS
-4209 .1125 9B
-4210 .125 10BS 6FS
-4211 .1375 11B
-4212 .150 12B
-4213 .1625 13B
-4214 .175 14B
-4215 .1875 15B
-4216 .200 16B
-4217 .2125 17B
-4218 .225 18B
-4219 .2375 19B
3800-00-4401 .021 1F
-4402 .042 2F
-4403 .063 3F
-4404 .084 4FS
-4405 .105 5FS
-4407 .147 7F
-4408 .168 8F
-4409 .189 9F
-4410 .210 10F
-4411 .231 11F
bottom pin
part number length A2 A2 A4 A4
3800-00-3200 .107 0A 0E
-3201 .1195 1A
-3202 .132 2A
-3203 .1445 3A
-3204 .157 4A
-3205 .1695 5A 0J 3E 0K
-3206 .182 6A 1J
-3207 .1945 7AS 2JS
-3208 .207 8AS 3JS
-3209 .2195 9AS 4JS
3800-00-3401 .128 1E
-3402 .149 2E
-3404 .191 4ES 1KS
-3405 .212 5ES 2KS
6140-00-3205 .2325 5J 3K
-3206 .2445 6J
3207 .257 7J
-3208 .2695 8J
-3209 .282 9J
6140-00-3404 .254 4K
-3405 .275 5K
