Kaba Simplex Mechanical Pushbutton Locks User Manual

Access Control Catalog - June 2004
Simplex
®
19
Simplex
®
8100 Series
Heavy-Duty Lock
Items supplied with the lock:
- All hardware required for a complete installation- Full-scale template
- Combination change wrench
- Standard & ASA strikes
- Installation instructions
Example
814 6 41
Build the model number with the desired options
Model Finish Packaging
B
L
R
Key OverrideHanding
8
14
4
1
-
--
-
Front Exterior Back InteriorSide Exterior
9"
(229
mm)
7
3
⁄8"
(187 mm)
8"
(203
mm)
3
1
⁄8"
(79
mm)
3
13
⁄16"
(97 mm)
2
3
⁄8"
(60 mm)
1
1
⁄4"
(32
mm)
3
1
⁄4"
(83 mm)
LP
C
1
2
3
4
5
• Combination Entry
• Key Override
• Passage
• Lockout
Model 8146
• Combination Entry
• Key Override
• Passage
• Lockout
• Deadbolt
Model 8148
82D
You must specify the handing of your
door. Please see page ii for a guide.
Handing
L
Left Hand
LR
Left Hand Reverse
Bevel
R
Right Hand
RR
Right Hand Reverse
Bevel
Model
8146
Combination entry
Key override
Passage
Lockout
3
⁄4" (19 mm) two-piece latch
no deadbolt
8148
Combination entry
Key override
Passage
Lockout
3
⁄4" (19 mm) two-piece latch
with 1" (25 mm) deadbolt
Key Override
Compatible with removable core
cylinders (not supplied).
A
ASSA
B
Best & Compatibles (6 or 7-pin length)
C
Corbin/Russwin
M
Medeco*/Yale (6-pin length)
*5-pin Medeco cylinder requires a
special knob spacer. Request spacer
when ordering, part number 201569
(supplied free of charge)
R
Sargent
S
Schlage
Finishes
03
Bright Brass (605)
05
Antique Brass (609)
26D
Satin Chrome (626)
41
1 per box
Locks
shipped
3 per case
Packaging
