Access Control Catalog - June 2004
Simplex
®
23
Simplex
®
3100Series
Narrow Stile Lock
Lock Operation
Combination code: One code per lock made of any combination of one to five numbers (pressed individually
or simultaneously)
Code: Thousands of possible combinations
Emergency access: Mechanical Key override
Certification and Testing
Accessibility standard: Americans with Disabilities Act (ADA) compliant push / pull paddles
Environmental Highly weather resistant
operating conditions:
Durability:
Conforms to ANSI 156.5
Warranty: 1 year
Mechanical Features
Construction: Heavy-duty American zinc-case mortise; all metal; cast front housing
Installation: Retrofits Adams Rite 4510 / 4710 mortise latch preparations. Through bolt installation restricts forcible
removal of the front housing.
Door handing: Factory-handed; not field reversible
Numeric pushbuttons: Vandal resistant, 5 button, plus Enter button, anodized aluminum, mechanical
Weight: 8 lbs. (3.6 kg)
Stile width: 1
7
⁄8" (48 mm) minimum, 2" (51 mm) maximum required for mounting
Stile thickness: 1
3
⁄4" (44 mm) maximum
Strike: Compatible to Adams Rite
Latch: Mortise latch, heavy-duty
5
⁄8" (19 mm) thick bolt with dead latch
Backset:
31
⁄32" (25 mm) or 1
1
⁄8" (29 mm)
Finishes: Satin Chrome 26D (626); 55 (695) Duranodic
Control: Combination change tool and wrench
