Access Control Catalog - June 2004
Simplex
®
Simplex
®
8100 Series
Heavy-Duty Lock
Mechanical Features
Construction: Cast front housing; brass unified trim plate; fixed cast ADA - compliant levers
Installation: Standard (86) mortise preparation.
Door handing: Factory-handed; not field reversible
Numeric pushbuttons: Vandal resistant, 5 button, anodized aluminum, mechanical
Minimum stile 5" (127 mm)
requirement:
Weight:
9.8 lbs. (3.7 kg)
Strike: 4
7
⁄8" (124 mm) L x 1
1
⁄4" (32 mm) W x
1
⁄4" (6 mm) Deadbolt/ Latch mortise strike plate
Latch: 1" (25 mm) optional deadbolt;
3
⁄4" (19 mm) two-piece anti-friction latch; accommodates
1
⁄2" (13 mm) throw
Backset: 2
3
⁄4" (70 mm)
Key override: Compatible with major manufacturers of removable cores: ASSA, Best and Compatibles (6 or 7-pin
length), Corbin/Russwin, Medeco/ Yale (6-pin length), Sargent, Schlage
Door thickness: 1
3
⁄4" (44 mm) to 2
1
⁄4" (57 mm)
Finishes: Bright Brass 03 (605); Antique Brass 05 (609); Satin Chrome 26D (626)
Control: DF5 keys or thumbturn for passage and lockout
Lock Operation
Combination code: One code per lock made of any combination of one to five numbers (pressed individually
or simultaneously)
Code: Thousands of possible combinations
Emergency access: Optional mechanical key override
Certification and Testing
Accessibility standard: Americans with Disabilities Act (ADA) for lever equipped lock
Fire rating: Three-hour UL/ULC Fire rating for “A” label doors
Environmental Highly weather resistant
operating conditions:
Durability:
Conforms to ANSI 156.13
Warranty: 1 year
