Access Control Catalog - June 2004
Simplex
®
Simplex
®
LP1000Series
Exit Device Operator
Lock Operation
Combination code: One code per lock made of any combination of one to five numbers (pressed individually
or simultaneously)
Code: Thousands of possible combinations
Emergency access: Mechanical Key override
Certification and Testing
Accessibility standard: Americans with Disabilities Act (ADA) for lever equipped lock
Fire rating: Three-hour UL/ULC rating for “A” label doors
Environmental Highly weather resistant
operating conditions:
Durability:
Conforms to ANSI 156.2, Grade 1
Warranty: 1 year
NOTE: Exit Device may be “Dogged” without affecting the LP1000.
Mechanical Features
Construction: Heavy-duty cylindrical lock housing; all metal; cast front housing; brass mounting plate; fixed cast ADA-
compliant lever
Installation: Recessed through bolts may be required. Exit Device preparation.
Door handing: Factory-handed; not field reversible
Numeric pushbuttons: Vandal resistant, 5 button, anodized aluminum, mechanical
Weight: 8 lbs. (3.6 kg)
Strike: Not supplied. (Comes with Exit Device)
Latch & Exit Device: Not supplied
Key override: Compatible with major manufacturers of removable cores: ASSA, Best and Compatible (6 or 7-pin length),
Corbin / Russwin, Medeco / Yale (6-pin length), Sargent, and Schlage
Exit Device • Von Duprin Exit Only (EO) or Exit Only Fire (EOF) 22, 88 NL, 98, 99, 9857, 9957
compatibility: • Dorma 9100, 9300, 9400
• Detex Advantex Series 10, 20, 21, 40, 50, 51
• Monarch XX-R*, FXX-R, 18-R*, F-18-R*, XX-V*, F-XX-V*, 18-V*, F-18-V* (*Requires special
k-hub adapter)
• Cannot be used with mortise design or most vertical rod Exit Devices
Tailpiece: 2
3
⁄4" (70 mm) tailpiece for Exit Device operation from outside
Exit Device hub Up to 60˚, counterclockwise for left hand & clockwise for right hand
rotation:
Door thickness:
1
3
⁄8" (35 mm) to 2
1
⁄4" (57 mm); optional 4" (102 mm)
Finishes: Satin Chrome 26D (626), Bright Chrome 026 (625)
Control: Combination change tool
Minimum stile 5" (127 mm)
requirement:
