Access Control Catalog - June 2004
Simplex
®
27
Simplex
®
LP1000Series
Exit Device Operator
Front Exterior Back InteriorSide Exterior
ModelHanding
Compatible with removable core
cylinders (not supplied).
A
ASSA
B
Best & Compatibles
(6 or 7-pin length)
C
Corbin/ Russwin
M
Medeco*/Yale (6-pin length)
*5-pin Medeco cylinder requires a
special knob spacer. Request spacer
when ordering, part number 201569
(supplied free of charge)
R
Sargent
S
Schlage
026
Bright Chrome (625)
26D
Satin Chrome (626)
41
1 per box
Key override Finishes Packaging
8
3
⁄4"
(222 mm)
4
3
⁄8"
(111 mm)
3
7
⁄8"
(98 mm)
2
7
⁄16"
(62 mm)
LP1010
Combination entry
LP1020
Combination entry
Key override
L
Left hand
Reverse bevel
R
Right hand
Reverse bevel
Not Supplied
1
2
3
4
5
Items supplied with the lock:
- Combination change tool
- All hardware required for a complete installation on the access side of the door
- Installation instructions
- Full-scale template
• Combination entry
• Egress with Exit Device (Not supplied)
LP1010
• Combination entry
• Egress with Exit Device (Not supplied)
• Key override (Not supplied)
LP1020
You must specify the handing of your
door. Please see page ii for a guide.
Example
1020PLL641
Build the model number with the desired options
Model Finish PackagingHanding
B
Key Override
P
L
L
1 0
4
1
-
--
-
2
D
2 0
