Kaba Simplex Mechanical Pushbutton Locks User Manual

Front Exterior Back InteriorSide Exterior
Model Access
Locking Device
Compatible with
removable core
cylinders
(not supplied).
A
ASSA
B
Best &
Compatibles
(6 or 7-pin length)
C
Corbin/ Russwin
M
Medeco*/Yale
(6-pin length)
R
Sargent
S
Schlage
03
Bright
Brass (605)
05
Antique
Brass (609)
26D
Satin
Chrome (626)
41
1 per box
1
1
⁄2" (13 mm)
throw latch
floating
face plate
5
3
⁄4" (19 mm)
throw latch
floating
face plate
Locking Device
1
1
⁄2" (13 mm)
throw latch
floating face
plate
5
3
⁄4" (19 mm)
throw latch
floating face
plate
Key Override
Compatible with
removable core
cylinders
(not supplied).
A
ASSA
B
Best &
Compatibles
(6 or 7-pin length)
C
Corbin/ Russwin
M
Medeco*/Yale (6-pin length)
*5-pin Medeco cylinder requires a
special knob spacer. Request spac-
er when ordering, part number
201569 (supplied free of charge)
R
Sargent
S
Schlage
Key Override Finishes Packaging
3
13
⁄16"
(97
mm)
2
3
⁄8"
(60 mm)
101
Combination
entry
102
Combination
entry
Key override
Model Egress
Example
Build the model number with the desired options
Model Model Locking DeviceLocking Device Key Override Finish PackagingKey Override
1
/
/
0
41
1E E02
--
6
41
--
EE
1
0
E
E
1B 1E E011B
1
2
3
4
5
Simplex
®
EE1000 Series
Heavy-Duty Lock
D2
101
Combination
Egress
102
Combination
Egress
Key override
Items supplied with the lock:
- All hardware required for a complete installation- Full-scale template
- Combination change access torx wrench
- Standard & ASA strikes
- Installation instructions
• Combination Entry
• Combination Egress
Model EE1011/ EE1011
• Combination Entry
• Combination Egress
• Key Override Entry
Model EE1021/EE1011
• Combination Entry
• Combination Egress
• Key Override Entry
• Key Override Egress
Model EE1021/EE1021
3
1
⁄8"
(79 mm)
7
3
⁄8"
(187 mm)
1
2
3
4
5
Access Control Catalog - June 2004
17
