Simplex
®
EE1000 Series
Heavy-Duty Lock
Mechanical Features
Construction: Heavy-duty cylindrical lock housing with cast front and back housing; wrought brass knobs
Installation: ASA 161 door preparation with 4 additional through bore holes [(2)
1
⁄2" (13 mm) and (2)
5
⁄16" (8 mm)
diameter] required for mounting lock.
Door handing: Field reversible
Numeric pushbuttons: Vandal resistant, 5 button, anodized aluminum, mechanical
Weight: 10.25 lbs. (4.6 kg)
Strike: Standard strike plate; ASA strike plate; strike box
Latch:
1
⁄2" (13 mm) throw latch
Backset: 2
3
⁄4" (70 mm)
Key override: Compatible with major manufacturers of removable cores: ASSA, Best and Compatibles (6 or 7-pin
length), Corbin/Russwin, Medeco/ Yale (6-pin length), Sargent, Schlage
Minimum stile 5" (127 mm)
requirement:
Door thickness:
1
3
⁄4" (44 mm) to 2
1
⁄4" (57 mm); Modified lock for more than 2" (51 mm) thick door available (specify
when ordering).
Finishes: Bright Brass 03 (605); Antique Brass 05 (609); Satin Chrome 26D (626)
Control: Anti-Tamper Torx Tool Bit for gaining access to combination change.
Lock Operation
Combination code: One code per lock made of any combination of one to five numbers (pressed individually
or simultaneously)
Code: Thousands of possible combinations
Emergency access: Optional mechanical key override
Certification and Testing
Fire rating: Three-hour UL/ULC Fire rating for “A” label doors
Environmental Highly weather resistant
operating conditions:
Durability:
Conforms to ANSI 156.2, Grade 1
Warranty: 1 year
Access Control Catalog - June 2004
16
