Access Control Catalog - June 2004
Simplex
®
Simplex
®
900 Series
Light Commercial/ Residential Locks
Mechanical Features
Construction: All metal; cast rear housing; force-proof clutch-protected thumbturn; exterior brass trim plate
Installation: Rim type spring latch (surface mounted on inside of door); through-bore 1
5
⁄8" for barrel,
3
⁄4" (19 mm)
for thumbturn and
7
⁄8" (22 mm) for optional key override; face plate covers mounting holes
Door handing: Field reversible latch. Invert the lock for right hand doors. Roman numerals are easily read in
either orientation.
Numeric pushbuttons: Vandal resistant, 5 button, anodized aluminum, mechanical
Weight: 4 lbs. (1.8 kg)
Strike: Includes strike plate for outswing doors, cast box strike for inswing doors. Metal door frames require
the optional surface mortise box strike, or use of an adapter kit (see accessories)
Latch: 1" (25 mm) deadbolt, or rim spring latch with deadlocking trigger and latch holdback
Backset: 2
9
⁄16" (65 mm) for outswing doors, 2
1
⁄2 (64 mm) for inswing doors
Door thickness: Standard models 1
3
⁄8" (35 mm) to 1
1
⁄2" (38 mm) or 1
3
⁄4" (44 mm) to 2
1
⁄8" (54 mm)
Model 929: Lockset for DOD standards, 1
3
⁄4" (44 mm) to 2
1
⁄8" (54 mm) only
Finishes: 04 (633) Satin Brass; 26D (626) Satin Chrome
Model 929: 26D (626) Satin Chrome
Control: Allen wrench for access to combination change
