Kaco blueplanet 3.0 TL3 M2 WM OD IIG0 User Manual

Country-
spec. Set-
tings
Men
u
level
Display/
Setting
Action in this menu/meaning
4
1 2
3
4
Parameters F Press the Right arrow button or Enter button.
NOTE:The device does not display the "Parameters" menu in
the standard configuration. To display the Parameters menu:
1. Open the menu.
2. Simultaneously hold down the Up and Down buttons for several
seconds.
4
1 2
3
4
Password protection
Status
On/Off
NOTE:Opportunity to set password protection.
F Selecting "yes" initiates a password request for the entire menu
item: Parameters.
4
1 2
3
4
Country
NOTE:This option influences the country-specific operating
settings of the device. Please consult KACO service for further
information.
1. Enter the four-digit password using the 4-way button. The password
is device-specific.
2. Confirm the entry with the Enter button.
3. Set the desired country setting.
CH, DE, ES,
FR, GB, GR,
IT, JO, JP,
LU, TH, ZA
4
1 2
3
4
Grid type/directive F Select the grid type for the device’s installation location.
UD
4
1 2
3
4
Nominal grid volt. F Set the specified grid voltage for the site where the device is used
(please contact KACO Service)
4
1 2
3
4
Grid parameter F Open the menu: Press the Right arrow button or Enter
button.
AT, BG, CZ,
FR-OLD,
FR-VFR13,
FR-VFR14,
IE, JP, NL,
PL, PT, TR,
TW, UD
4
1 2
3
4
Overvoltage shutd. 10
min. average
1. Specify the shutdown threshold for overvoltage trip-off.
ð The 10-minute average for the measured voltage as per
EN50160 is used.
2. Set period from occurrence of the fault to shutdown of the device.
BE CH-NS
CY DE-NS
DK LU-NS
4
1 2
3
4
Overvoltage shutd. 10
min. average Password
protection
1. Activate or disable password protection.
2. Specify the shutdown threshold for overvoltage trip-off.
ð The 10-minute average for the measured voltage as per
EN50160 is used.
3. Set period from occurrence of the fault to shutdown of the device.
AT FR-OLD
FR-VFR13
FR-VFR14
JP-50HZ
JP-60HZ
UD
4
1 2
3
4
Voltage drop
NOTE:The voltage drop between the device and the feed-in
meter is added to the limit value that was set for grid shut-
down according to EN 50160. The limit value can be set to
0-11 Volt increments.
F Specify the shutdown value for the voltage drop (0-11 Volt).
Manual Configuration and operation | 9
KACO blueplanet 3.0 TL3 KACO blueplanet 4.0 TL3 KACO blueplanet 5.0 TL3 KACO blueplanet 6.5 TL3 KACO
blueplanet 7.5 TL3 KACO blueplanet 8.6 TL3 KACO blueplanet 9.0 TL3 KACO blueplanet 10.0 TL3
Page 39
EN
