Kaco blueplanet 3.0 TL3 M2 WM OD IIG0 User Manual

Country-
spec. Set-
tings
Men
u
level
Display/
Setting
Action in this menu/meaning
BE CH-NS
CY DE-NS
DK LU-NS
4
1 2
3
4
Voltage shutdown
NOTE:The device is equipped with redundant 3-phase monit-
oring. If the grid voltage exceeds or drops below the con-
figured values, the device switches off. The minimum switch-
off threshold can be set in 1Volt increments.
1. Configure the switch-off values for undervoltage and overvoltage.
2. Where applicable, set period from occurrence of the fault to shut-
down of the device.
AT, AU, BG,
CH—MS,
CZ, DE-MS,
ES, FR, GB,
GR, HR,
HU, IE, IL,
IN, IT, JO,
JP, KR,
NL,PL, PT,
RO, TH,
TR,TW, DU,
ZA
4
1 2
3
4
Overvoltage shutd. 1. Specify the shutdown threshold for fast and slow overvoltage shut-
down.
2. Set period from occurrence of the fault to shutdown of the device.
See Over-
voltage
shutd.
4
1 2
3
4
Undervoltage shutd. 1. Specify the shutdown thresholds for fast and slow overvoltage shut-
down.
2. Set period from occurrence of the fault to shutdown of the device.
AT, AU, BG,
CD-MS, CZ,
DE-MS, ES,
FR, GB, GR,
HR, HU, IE,
IL, IN, IT,
JO, JP, KR,
NL, PL, PT,
RO, TH, TR,
TW, DU, ZA
4
1 2
3
4
Overfreq. shutd. F Set limit value for the slow and fast overfrequency shutdown.
}Page000
]
4
1 2
3
4
Underfreq. shutd. F Set limit value for the slow and fast underfrequency shutdown.
9 | Configuration and operation Manual
KACO blueplanet 3.0 TL3 KACO blueplanet 4.0 TL3 KACO blueplanet 5.0 TL3 KACO blueplanet 6.5 TL3 KACO
blueplanet 7.5 TL3 KACO blueplanet 8.6 TL3 KACO blueplanet 9.0 TL3 KACO blueplanet 10.0 TL3
Page 40
EN
