Country-
spec. Set-
tings
Men
u
level
Display/
Setting
Action in this menu/meaning
4
1 2
3
4
Power limitation.
NOTE:The output power of the device can be set permanently
to a lower value than the maximum output power by the
power limitation. This may be necessary in order to limit the
maximum power rating of the system at the grid connection
point, upon the grid operator's request.
NOTE:The value can be protected from the very first power
limitation entry. After setting a limitation, the value can only
be changed by entering a device-specific password.
NOTE:Only the external power limitation can be adjusted on
the device. The internal power limitation can only be set via
the web interface.
[See section9.4.2}Page45]
4
1 2
3
4
Power limitation. ex-
ternal
NOTE:External power limitation is possible with the extension
module (KACO accessories).
1. Specify the activation status (on / off).
2. Select the activation threshold (Active Low / Active High) from di-
gital input 1, 2, 3 or 4 (only if activation status = on).
3. Specify the power limitation stages (only if activation status = on) a.)
Specify stage 0-3 b.) Specify stage 4-7 c.) Specify stage 8-11 d.) Spe-
cify stage 12-15
4. Confirm the entry with the Enter button.
4
1 2
3
4
Enh. Parameters F Further parametrization possible via WEBGUI!
4
1 2
3
4
Powador-protect
Auto | On | Off
NOTE:Configures the support for grid shutdown via a
Powador protect connected to the „INV OFF“ input of the
device.
Auto/On: A Powador-protect is operating in the photovoltaic sys-
tem and is connected to the device at the „INV OFF“ input.
F Set the operating mode for Powador-protect.
Auto: The device automatically detects a Powador-protect integrated
into the photovoltaic system.
On: The digital signal of the Powador-protect must be present at the di-
gital input of the device for the device to begin feed-in.
Off: The device does not check whether a Powador-protect is integrated
into the PV system.
4
1 2
3
4
Insul. resistance F Set threshold value (in 1kOhm increments) at which the insulation
monitor reports a fault.
4
1 2
3
4
Power reduction P(f)
. NOTE:The unit supports the internal power factor correc-
tion after P(f).
1. )Open the menu: Press the Right arrow button or Enter
button.
2. Note: All the parameters are configurable here and via the WEB in-
terface. [See section9.4.2}Page45]
Not for IL,
IT
4
1 2
3
4
P(f) operation mode
Off | Mode 1 |
Mode 2
NOTE:More detailed information can be found in
F Specify the operation mode.
9 | Configuration and operation Manual
KACO blueplanet 3.0 TL3 KACO blueplanet 4.0 TL3 KACO blueplanet 5.0 TL3 KACO blueplanet 6.5 TL3 KACO
blueplanet 7.5 TL3 KACO blueplanet 8.6 TL3 KACO blueplanet 9.0 TL3 KACO blueplanet 10.0 TL3
Page 42
EN
