Kaco blueplanet 3.0 TL3 M2 WM OD IIG0 User Manual

No. Grid
LED
LED Display Status description Action Pers
.
21 Generator overcurrent error
1
The DC current has exceeded the permissible
maximum value on PVx. A shutdown is carried
out to protect the device.
How much gener-
ator power is con-
nected? The risk of
a shutdown is
higher if the oversiz-
ing is excessive and
the PV voltage is
lower.
B
22 Generator overcurrent error
2
See description in the event of an error 21 See action in the
event of an error 21
B
29 Check ground fault fuse DC side ground fault A ground fault was detec-
ted on the DC side. There is the option of
switching this on in all country versions via a
display entry. Ground fault monitoring is al-
ways active in the USA.
Check the solar gen-
erator for an inad-
missible ground
fault.
E
30 Voltage trans. fault Current and voltage measurement in the
device are not plausible.
Switch off the
device entirely
(switch off AC + DC
for min. 5 minutes),
if the fault occurs
again, contact the
service department
B
31 AFI module fault Current offset during automatic offset adjust-
ment too great.
Disconnect the
device from the AC
and DC supply.
Switch it back on
after several
minutes. If this does
not resolve the is-
sue, notify your au-
thorized electrician
B E
32 Self test error The internal grid separation relay test has
failed.
Notify your author-
ized electrician if
the fault occurs re-
peatedly!
E
33 DC feed-in error The DC feed-in has exceeded the permitted
value. This DC feed-in can be caused in the
device by grid conditions and may not neces-
sarily indicate a fault.
E
34 Internal communication er-
ror
A communication error has occurred in the in-
ternal data transmission.
Contact a qualified
electrician! Check
the data cable.
E
35 Protection shutdown SW Protective shutdown of the software (AC over-
voltage, AC overcurrent, DC link overvoltage,
DC overcurrent, DC overtemperature).
Not an error! Grid-
related shutdown,
the grid connects
again automatically.
-
36 Protection shutdown HW Group error for all trip zone shutdowns, gener-
ally the precise shutdown reason appears first,
followed by this group error.
Cause: Saturation monitoring of the AC IGBTs
or AC overcurrent. Protective shutdown when
critical limits are exceeded, hardware.
Not an error! Grid-
related shutdown,
the grid connects
again automatically.
-
11 | Maintenance and troubleshooting Manual
KACO blueplanet 3.0 TL3 KACO blueplanet 4.0 TL3 KACO blueplanet 5.0 TL3 KACO blueplanet 6.5 TL3 KACO
blueplanet 7.5 TL3 KACO blueplanet 8.6 TL3 KACO blueplanet 9.0 TL3 KACO blueplanet 10.0 TL3
Page 78
EN
