No. Grid
LED
LED Display Status description Action Pers
.
37 Unknown hardware No valid version of the power unit was detec-
ted. Incorrect hardware installed.
Switch DC + AC off -
> Wait 5 min. -> If
the fault is still
present then ar-
range for a service
to take place. The
firmware on the
device does not
support the hard-
ware available. -->
use suitable firm-
ware
B E
38 Error: Generator Voltage too
high Error: Battery over-
voltage
PV overvoltage error The solar voltage of the
generators has exceeded the permissible max-
imum value
Contact a qualified
electrician!
E
41 Grid failure undervoltage L1 Grid failure over/undervoltage Lx grid voltage
Lx below set minimum permissible grid voltage
Check AC voltage at
connection termin-
als. Check set values
in the parameter
menu. Contact the
service department
if the error persists
E
42 Grid failure overvoltage L1 See description in the event of a fault 41 See action in the
event of a fault 41
E
43 Grid failure undervoltage L2 See description in the event of a fault 41 See action in the
event of a fault 41
E
44 Grid failure overvoltage L2 See description in the event of a fault 41 See action in the
event of a fault 41
E
45 Grid failure undervoltage L3 See description in the event of a fault 41 See action in the
event of a fault 41
E
46 Grid failure overvoltage L3 See description in the event of a fault 41 See action in the
event of a fault 41
E
47 Grid failure phase-to-phase
voltage
The phase angle between the individual
phases of the three-phase supply network is
not correct, possibly no three phase connec-
tion
see action in the
event of a error 42
B/K
48 Grid failure underfrequency Grid frequency below the minimum permiss-
ible grid frequency set
Check set values in
the parameter
menu. Fault can be
caused by a poor
connection on the
AC side. Check con-
nection terminals
from the device to
the grid connection.
E
49 Grid failure overfrequency Grid frequency above the maximum permiss-
ible grid frequency set
see action in the
event of an error 48
E
50 Grid failure: average voltage The grid voltage measurement according to EN
50160 has exceeded the maximum permitted
limit value. This fault may be grid-related.
Contact a qualified
electrician!
E
56 SPI Remote disconnection Shutdown via digital input Remote control for
Italy CEI 0-21 Remote trip Off
- -
Manual Maintenance and troubleshooting | 11
