Appendix
Operating Instructions Powador . TL, . TL, . TL_EN Page 
Connection examples
Input 1 Input 2 Input 3 Input 4
Voltage Power Voltage Power Voltage Power Voltage Power
400 V 3500W 400 V 3500W 700 V 3500W 700 V 3500W
600 V 7000W Unconnected 500 V 7000W Unconnected
500 V 12800W Unconnected Bridged to 1 Unconnected
500 V 5000W 500 V 5000W Unconnected 750 V 4000W
750 V 6000W 750 V 6000W 350 V 1000W 350 V 1000W
600 V 6000W Unconnected Short-circuited Short-circuited
Invalid connections
Invalid switching states are shown in the following table with a dark background:
Input 1 Input 2 Input 3 Input 4
Voltage Power Voltage Power Voltage Power Voltage Power
400 V 3500W 700 V 3500W 400 V 3500W 700 V 3500W
600 V 7000W 600 V 7000W Unconnected Unconnected
500 V 12800W Bridged to 1 Unconnected Unconnected
600 V 6000W Short-circuited Short-circuited Unconnected
