KAL-FIRE Fairo 60 - 7.2.2 Replacing the glass (60-70-75-100-120-140-160)

7. Maintenance
44
7.2.2 Replacing the glass (60-70-75-100-120-140-160)
1. Slide the window to the
right. Pay attention that the
side panel is facing inwards
and that there are no stones
or chips between door and
the burner cover. The
operating rod is facing
forward.
2. Place the window back in the
appliance by moving it to the
left and pressing it
downwards.
3. Fold the side panel outwards
with a turning and pulling
movement.
4. Slide the operating rod back
into place.
