KAL-FIRE Fairo 60 - 7.2.3 Removing the glass from the Fairo 105 Tunnel and Fairo 105 Front

8. Trouble shooting
45
5. Slide the seal downwards.
6. Place the magnets in the
right position and replace the
frame.
7.2.3 Removing the glass from the Fairo 105 Tunnel and Fairo 105
Front
1. Remove the profile strip.
2. Remove the 3 socketed
screws and the 2 magnets.
3. Slide the bar upwards and
then to the left.
