Kalkomat Boxer - Speaker; Ticket Dispenser; Hopper

40
3 & 4 – GAME selection
5 & 6 – bulbs lighting button Start
7 & 8 – bulbs lighting button Game
Speaker
1 - speaker
2 - speaker
3 - unused
4 - unused
J 4
Ticket dispenser
1 - red (+12V)
2 - green (signal)
3 - black (-12V)
Hopper
Motor
Hopper
1
2
3
