9 – 900 (-)
10 – 900 (+)
11 – Select Game (-)
12 – Select Game) (+)
13 – speed (-)
14 – speed (+)
15 – Reflex (-)
16 – Reflex (+)
Paper Money Depositor
1 – Credit relay (Common) normally purple. Pin#8 at the ICT
connector
2 – +12V (Power) normally red. Pin#5 at the ICT connector
3 – GND (Power) normally orange. Pin# 9 at the ICT connector
4 – Credit relay (N.O) normally blue. Pin# 7 at the ICT connector
11. Spare parts and equipment
- leveling legs 4 pieces
- punching bag pump 1 piece
- bladder 1 piece
12. Standard replacement parts
- Front panel bulbs (#73 bulb)
- SELECT GAME button bulb (#161)
- Main power supply (Switching power supply – 12V, 12A -
5V, 5A)
- Halogen bulb (12v 20W, MR11/C (GU4) – 35mm DIA.)
13. Required tools and equipment for servicing the
boxing game
- Metric wrench set from 8mm to 19mm (preferably with
ratchet)
- Long Allen wrench from 8mm to 19mm
- Snap ring pliers for inside diameters
