9. Quick check for potential errors
Main board not functioning:
1 Check all fuses (5A).
2 Check the connection between main power supply and the main
board.
3 Make sure that the main processor and other connectors are well
seated.
4 All displays can be checked by turning the switch #1 to “ON”
position than turning machine off and back on.
Coin Acceptor is not functioning:
1 Check if it is not clogged up.
2 Check for dust and dirt.
3 Check strip connecting the main board with the acceptor.
Mechanism is not functioning:
1 Using just power supply check if it is possible to lower
punching bag (using manual switch, black button above the 12V
connector - see drawing #4 or drawing #5).
2 Check for burned fuse 30A.
3 Check button functionality and if they have proper connection.
4 Check for unhooked cable from power supply spools.
5 Check strip connecting the main board with the power supply.
