Dip Switch 1-8 (S1)
THE RED (BLACK OR BLUE) SWITCH BOX WITH 8 SWITCHES IS
LOCATED ON THE LEFT SIDE OF THE MAIN CIRCUIT BOARD. TO
PROGRAM, SWITCH #1 MUST BE SET TO "ON" POSITION WHEN
MACHINE IS “ON”.
PUSH BUTTONS SW1 ↑ AND SW2 ↓ ARE LOCATED IN THE LOWER LEFT
PART OF THE MAIN CIRCUIT BOARD.
Switch #1
THIS SWITCH IS USED TO ENTER THE PROGRAM SETTINGS.
PLEASE USE BUTTONS SW1 ↑ OR SW2 ↓ FOR FINDING THE
RIGHT PROGRAM P01-P96. DESCRIPTIONS FOR EACH
PROGRAM ARE LISTED BELOW. DURING PROGRAM
SELECTION YOU WILL SEE P01-P96 ON THE MAIN DISPLAY.
REMEMBER, FOR SOME SETTINGS YOU WILL USE “START
BOXING”, “START KICKING” OR “SELECT GAME” BUTTONS.
