Kane 258 - Report Navigation and Temperature Testing; Temperature Testing Procedure

21KANE 258 MANUAL
REPORT NAVIGATION MENU OPTIONS
Print currently selected report
Navigate to next available report if more
than one report
Navigate to previously selected report -
only once navigation begins
Return to main menu
TEMPERATURE TESTING
Rotate dial to TEMP & connect your K type thermocouples to T1 to
measure temperature or T1 & T2 to measure dierential temperature.
T2 Temperature T1 Temperature
Use T1 connection for flow temperature
sensor
Use T2 connection for return
temperature sensor
Real time temperature difference
Status bar
TEMPERATURE DISPLAY
