Kanmor tekmarNet 4 - Job Record and Technical Data; Job Record Log; Technical Specifications

23 of 24 © 2011 D 538e - 02/11
Job Record
Item Setting
Set Room Heat
Set Room Heat
Set Room Heat Away
Set Floor Heat
Set Floor Heat
Backlight
Units
Max Set Room Heat
Max Set Room Heat
Min Set Room Heat
Item Setting
Set Floor Min
Set Floor Min
Set Floor Max
Schedule Member
Room Sensor
Sensor
Heat Cycles Per Hour
Heating Supply Pump
tekmarNet
®
Address
Jobsite Location ________________________________________________
Thermostat Location _____________________________________________
Technical Data
tekmarNet
®
4 Thermostat 538e; One Stage Heat
Packaged weight 380 g
Enclosure NEMA 1, white PVC plastic
Dimensions 73 x 73 x 21 mm
Approvals CE Approved
Ambient conditions Indoor use only, 2 to 50°C.
RH max 92% to 40°C, and 50% above 40°C
Altitude <3000 m, Installation Category II, Pollution Degree 2
Power supply
24 V (ac) ± 10% 50/60 Hz, 1.8 VA Standby, 56 VA fully
loaded, NEC / CEC Class 2
W Relay 24 V (ac) 2 A
Sensors: NTC thermistor, 10 kΩ @ 25°C ± 0.2°C ß = 3892
– Optional kanmor type # 070e, 071e, 076e, 079e, 082e, 084
