KT-300 Door Controller Installation Manual
Electrical Specifications
KT-300 Controller and Accessories
VOLTAGE OUTPUTS MAXIMUM
CURRENT
(N.A.)
MAXIMUM
CURRENT
(EU)
ABSOLUTE
COMBINED
MAXIMUM
(N.A.)
ABSOLUTE
COMBINED
MAXIMUM
(EU)
Lock Outputs (12 VDC) 500 mA
(250 mA each)
1.0 A
(500 mA each)
Auxiliary Power (11.5 to 13.85 VDC) 175 mA 175 mA
Reader 5 VDC and 12 VDC 175 mA 175 mA
Combus 500 mA 500 mA
Battery Charging (12 VDC) 250 mA 250 mA 1.5 A 2.0 A
OPEN COLLECTOR OUTPUTS MAXIMUM
CURRENT
LED (Door 1 & 2) 25 mA (each) 25 mA (each)
Buzzer (Buz, Door 1 & 2) 25 mA (each) 25 mA (each)
Controlled Relay 1 & 2 (RL1 & RL2) 25 mA (each) 25 mA (each)
Kantech Model Description
KT-300/512K Door controller with 512K memory including KT-300CAB, KT-300ACC and KT-
LOCK
KT-300PCB/512 KT-300/512K PCB only and KT-300 ACC (not UL listed)
KT-300ACC Accessory kit including: 2 X 1.0k ohm, 10 x 5.6k ohm, 2 x 120 ohm, PCB standoffs,
lock hole cover, ground wire and screwdriver
KT-PC4108 8-zone input expansion module for KT-300
KT-PC4204 4-Relay and Combus additional power supply module for KT-300
KT-PC4216 16-Output expansion module for KT-300
KT-RM1 External isolation relay SPDT for KT-300 output (RL1/RL2) (not UL listed)
KT3-LCD Time & date LCD display unit for KT-300
KT-300CAB KT-300 black metal cabinet including KT- LOCK
KT-4051CAB Standard black metal cabinet for KT-PCxxx modules (order keylock separately)
KT-LOCK Keylock for KT-300CAB/KT-4051CAB metal cabinet (2keys/same as KT-200)
KT-TAMP Tamper switch for KT-300CAB/KT-4051CAB metal cabinet
TR1637W/CSA Transformer, Wire-in, 110V/16V (37VA) CSA (not UL listed)
TR1640P/CSA Transformer, Plug-in, 110V/16V (40VA) CSA (not UL listed)
TR1640P/UL Transformer, Plug-in, 110V/16V (40VA) UL or DSC PTD1640 www.dsc.com
TR1640W-220 Transformer, Wire-in, 230V/16V (40VA) CE (not UL listed)
