Installing /Upgrading the agency mapping file
The agency mapping file T600Cfg.xml included in the supplied CR-ROM /software package is installed when installing
the T600 PC software.
To install updates on the agency mapping file provided by Kapsch TrafficCom (see constraints in page 37), follow these
steps.
Use Windows Explorer to copy the agency mapping file T600Cfg.xml into the installation folder created in
Installing the T600 software on page 37.
Launch the T600 software as Administrator by right-clicking the executable T600TagTester.exe and select Run as
administrator option to have the new mapping file take effect.
Note: User is advised NOT to modify the agency mapping file. Incorrect settings may cause improper function of the
T600 Tag Tester. Contact Kapsch TrafficCom for new update on the file.
Configuring the T600 tag tester communication settings
You must configure communications between the customer-supplied computer and the TTU and its internal scanner
before OBU testing begins.
Prerequisites: - The T600 hardware and software is installed.
- You must know the COM port numbers of the computer serial ports which connect to the T600
hardware.
Configuring communications between the TTU and the computer
Click Settings→Configuration. The Configuration Dialog window opens.
Click on the Communications tab in the Configuration Dialog window.
Select the computer COM port that connects to the TTU HOST port from the T600 Comm. Port drop-down box.
Select 9600 from the T600 Baud Rate drop-down box. Click OK.
Ensure the computer COM port that connects to the TTU HOST port is set to 9600 bps.
Configuring communications between the internal bar code scanner and the computer
Click Settings→Configuration. The Configuration Dialog window opens.
Click on the Communications tab in the Configuration Dialog window.
Select the computer COM port that connects to the TTU SCANNER port from the Scanner Comm. Port drop-down
box. Click OK.
Exit and relaunch the T600 software for changes to take effect.
