MACRO REMOTE
4
more than 2 seconds, all outputs
will keep their previous status.
BELT
To start the BELT from an off
state: Hold BELT FAST for 3s or
more, after 3s LOWER DOOR UP
output turns ON for 0.75s, then
BELT will turn ON at 10%. Upon
activation, the output will stay
on for 20 minutes and then it
will shut down.
Pressing the BELT FAST will
increase the output for 10% at a
time. This percentage is
adjustable using the Gate. If the
button is hold for more than 3
seconds, the output goes to
100%.
Pressing BELT SLOW will
decreased the output 10%.
Holding the button for more than
10 seconds will turn the output
off.
Pressing the STOP, BELT STOP,
LOWER DOOR DOWN or both
BELT FAST and SLOW at the
same time will turn the output
off.
Upper Door Open
Pressing this button activates
LOWER DOOR UP output for
0.75 seconds and then AIR
LATCH OPEN activates for 3
seconds. At the end the UPPER
DOOR OPEN output comes on for
6 seconds.
Upper Door Close
Pressing this button activates
UPPER DOOR CLOSE and AIR
LATCH OPEN outputs for 9
seconds and then AIR LATCH
CLOSE activates for 6 seconds.
At the end the LOWER DOOR
