Kärcher BP 3 Home User Manual

– 5
Technical specifications
BP 3 Home BP 5 Home
Voltage V 230 230
Frequency Hz 50 50
Output P
nom
W 800 1100
Max. flow rate l/h 3000 4500
Max. Suction height m 7 8
Max. pump pressure MPa (bar) 0,36 (3,6) 0,5 (5,0)
Working pressure MPa (bar) 0,17 - 0,28 (1,7 - 2,8) 0,19 - 0,3 (1,9 - 3,0)
Max. air pressure in the storage tank MPa (bar) 0,18 - 0,2 (1,8 - 2,0) 0,18 - 0,2 (1,8 - 2,0)
Max. permissible internal pressure in the storage
tank
MPa (bar) 0,50 (5,0) 0,50 (5,0)
Weight kg 11,5 14,7
Subject to technical modifications!
Operating pressure and transported quantity depends on the suction height and the connected periphery!
The possible delivery rate is even larger:
- the lower the suction and flow heights
- the larger the diameter of the hoses used,
- the shorter the hoses used are
- the lower the pressure loss caused by the connected accessories
14 EN
Ташев-Галвинг ООД
www.tashev-galving.com

Kärcher BP 3 Home Specifications

General

Type	Booster pump
Proper use	Water purification
Product color	Black, Yellow
Housing material	Stainless steel
Suitable for indoor use	Yes
Suitable for outdoor use	-
Flow rate	3000 l/h
Maximum suction height	7 m
Maximum delivery height	36 m
Maximum operating pressure	3.6 bar
Maximum input water temperature	35 °C
Power cable type	H05RN-F
Power source type	AC
Cable length	1 m
Connecting thread type	G1

Weight and Dimensions

Depth	450 mm
Width	270 mm
Height	550 mm
Weight	11300 g
