BR/BD 55/60 WP Machine functions
Service Information International 02.2003
Brush drive assembly (cover removed)
1 Drive motor, rear brush roller
2 Brush roller
3 Toothed belt
4 Motor fastening screws and toothed belt
5 Guide shoe
3
1
4
2
5
