ASSEMBLY INSTRUCTIONS- KÄRCHER COMPACTA & KÄRCHER PRACTICA BLACK
Unpacking the device
After opening the packaging, remove all parts and check the following list to
see which components are included:
1. Adjustable nozzle
4. Carrying handle
7. ON/OFF switch
10. Hose holder
13. Water inlet connector
16. Screw package
2. Spray lance
5. Power cord holder
8. Power cord
11. Water inlet connection
14.Detergent Nozzle
17. Manual
3. High pressure gun
6. Gun holder
9. Water outlet connection
12. High pressure hose
15. Cleaning pin
18. Quick connection
*The machine must always have the handle mounted for transportation.
1
2
3
5
8
6
9
10
11
4
2
3
4
6
10 12
13
15 16
14
1
M4*16 mm, 4 pieces
17
18
5
7
*Illustrative image, the client must follow according to the model purchased
