ASSEMBLY INSTRUCTIONS - KÄRCHER WASH JET
1. Adjustable nozzle
4. Carrying handle
7. ON/OFF switch
10. Hose holder
13. Water inlet connector
16. Screw pack
19. Wheels
2
3
5
8
6
9
10
11
4
2
3
4
6
10 12
13
15 16
14
1
M4*16 mm, 2 pieces
M4*22 mm, 2 pieces
17
18
5
7
19
181818
2 pieces
19
Unpacking the device
After opening the packaging, remove all parts and check the following list to
see which components are included:
*The machine must always have the handle mounted for transportation.
2. Spray lance
5. Power cord holder
8. Power cord
11. Water inlet connection
14.Detergent Nozzle
17. Manual
3. High pressure gun
6. Gun holder
9. Water outlet connection
12. High pressure hose
15. Cleaning pin
18. Quick connection
