6. Screw the high pressure hose onto the water outlet connection.
Push it in and turn it clockwise to tighten it and prevent leaks. When the parts are well
joined, you will not be able to separate the two components by pulling directly on the
water outlet.
ATTENTION: Before operating the machine, make sure that the high pressure hose is
completely uncoiled.
While the machine is in operation, the high pressure hose MUST NOT BE COILED.
②
①
7. Connect the other end of the high pressure hose to the gun.
Observation: After connecting the high pressure hose, check the connection by pulling
lightly on the hose to ensure that the hose remains connected. Push the locking button (1)
and pull it to disconnect the high pressure hose.
To easily disconnect the hose, press the trigger to empty the water from the lance when
the operation is complete and the switch is in the “OFF/0” position.
Press the button to remove the hose
34
