– 3
Dismount the brush cover if necessary:
Turn the turn-lock fasteners by 90° and
remove the brush cover.
Cut hair and threads that have got
wound on the brush roller using a pair of
scissors or just remove them.
Unlock and remove the filter cover.
Illustration
Turn the locking mechanism of the filter
bag towards the right. Close, remove,
and dispose of the filter bag.
Illustration
Insert a new filter bag and turn the lock-
ing mechanism of the filter bag towards
the left.
Insert and lock filter cover.
Unlock and remove the filter cover.
Push the locking mechanism of the filter
casing upwards and remove the filter
casing.
Remove the exhaust filter from the filter
housing.
Insert new exhaust filter into filter hous-
ing.
Insert and click the filter housing into its
place.
Insert and lock filter cover.
Unlock and remove the filter cover.
Push the locking mechanism of the motor
protection filter upwards. Remove and
dispose of the motor protection filter.
Install and lock the new motor protec-
tion filter.
Insert and lock filter cover.
Dismount the side part by means of a
coin.
Pull out the brush roller and dispose of.
Insert a new brush roller.
Reinstall side part.
Danger
First pull out the plug from the mains before
carrying out any tasks on the machine.
Illustration
Illustration
Illustration
Note: If necessary, dismount brush cover
(refer to "Cleaning of the brush roller").
No electrical voltage.
Check the receptacle and the fuse of
the power supply.
Check the power cable and the power
plug of the device.
Thermostat switched off the motor be-
cause of overheating
Replace blocked filters or remove
blockages from the suction hose.
The unit is operational again after it has
cooled down.
Note: The brush roller is equipped with a
slip clutch that disengages when oversized
or blocking objects are sucked in.
Note: The clutch is re-engaged after the
unit is switched off. This produces a loud
rattling sound.
Check the brush roller for obstructing
objects and remove them if necessary.
The noise can not be heard when the unit is
switched back on.
Cleaning the brush roller
Replacing the filter bag
Replace exhaust filter
Replace motor protection filter
Replacing the brush roller
Troubleshooting
Remove blockings
Suction pipe/suction hose
Suction hose on the brush head
Brush roller/brush head
Motor does not run
Rattling noise when switched off
12 EN
