Page #9 background imageLoading...
Page #9 background image
– 5
Technical specifications
CV 30/1 CV 38/1
Mains voltage V 220-240 220-240
Frequency Hz 50/60 50/60
Max. performance W 1150 1150
Air volume (max.) l/s 48 48
Negative pressure (max.) kPa (mbar) 20,7 (207) 20,7 (207)
Protective class II II
Length x width x height mm 985 x 380 x 250 1220 x 390 x 320
Width of the brush roller mm 300 380
Typical operating weight kg 8,6 9,2
Max. ambient temperature °C +40 +40
Values determined to EN 60335-2-69
Sound pressure level L
pA
dB(A) 68 68
Uncertainty K
pA
dB(A) 1 1
Hand-arm vibration value m/s
2
<2,5 <2,5
Uncertainty K m/s
2
0,2 0,2
Power cord H05VV-F 2x1,0 mm
2
Part no.: Cable length
EU 4.649-002.0 12 m
GB 4.649-003.0 12 m
AU 4.649-005.0 12 m
14 EN

Other manuals for Kärcher CV 30/1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kärcher CV 30/1 and is the answer not in the manual?

Kärcher CV 30/1 Specifications

General IconGeneral
Airflow43 l/s
Product typeUpright vacuum
Dust capacity5.5 L
Product colorBlack, Grey
Dust container typeDust bag
Standard nominal width- mm
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Maximum input power850 W
Noise level66 dB
Dirt separating methodFiltering
Working width (standard brush)300 mm
Weight and Dimensions IconWeight and Dimensions
Depth310 mm
Width320 mm
Height1220 mm
Weight8400 g
