Kärcher HD 5 12 - Rear View Component Identification; External Parts - Rear

New Unit Information 02.2004
Unit functions HD 5/12
Page 4 / 12
Rear view
1 Handle, height adjustable
2 Rear cover
3 Cleaning agent supply hose with filter
4 Wheel
5 Mains connection cable
6 Wheel
7 Cleaning agent metering valve
8 Clamping screw for adjusting handle
height
9 Handgun bracket
9
8
7
2
1
4
6
5
3
