Kärcher K 5.85 M Operating Instructions

English 9
Subject to technical modifications!
Australia
Kärcher Pty. Ltd.
40 Koornang Road
Scoresby, Victoria 3179
1800 675 714 (Free Call)
www.karcher.com.au
Specifications
Power connection
Voltage (1~50 Hz) 230-240 V
Connected load 2,1 kW
Mains fuse (slow-blow) 10 A
Protective class I
Protection class IP X5
Water connection
Max. feed temperature 40 °C
Min. feed volume 10 l/min
Max. feed pressure 0,6 MPa
Performance data
Working pressure 12,5 MPa
Max. permissible pressure 13 MPa
Water flow rate 7,5 l/min
Detergent flow rate 0-0,2 l/min
Recoil force of trigger gun 20 N
Hand-arm vibration
(ISO 5349)
0,8 m/s
2
Sound pressure level
L
pA
(EN60704-1)
78 dB(A)
Sound power level
L
WA
(2000/14/EG)
92 dB(A)
Dimensions
Length 400 mm
Width 365 mm
Height 900 mm
Weight 16,2 kg
Customer Service

Kärcher K 5.85 M Specifications

General

Brand	Kärcher
Model	K 5.85 M
Category	Pressure Washer
Language	English
