– 8
Technical specifications
Hydraulic connection
Supply from the hydraulic system of the MC 50
Connected load kW 6
Water connection
Supply from the water container of the MC 50
Max. feed temperature °C 60
Performance data
Working pressure (depends on the motor speed) MPa 10-14
Nozzle size 045
Max. operating over-pressure MPa 20
Flow rate (depends on the motor speed) l/h (l/min) 8-10
Max. recoil force of hand spray gun N 42
Values determined as per EN 60355-2-79
Hand-arm vibration value
Hand spraygun m/s
2
<2,5
Spray lance m/s
2
<2,5
Uncertainty K m/s
2
0,3
Sound pressure level L
pA
dB(A) 83
Uncertainty K
pA
dB(A) 3
Sound power level L
WA
+ Uncertainty K
WA
dB(A) 103
Fuel
Amount of oil l 0,95
Oil grade SAE 50
Dimensions and weights
Length mm 560
Width mm 700
Height mm 520
Weight kg 45
18 EN
