Kärcher Puzzi 8/1 C Instruction Manual

– 3
 Remove the dirt water reservoir from
the appliance and empty it.
 Spray and suction off detergent solution
in one work cycle.
Note
A repeated suctioning without spraying will
shorten the drying time.
 Apply detergent solution with suction
turbine turned off and soak for 10 to 15
minutes.
 Clean the surface just like with normal
soiling.
 In order to further improve the cleaning
result, the surface can be recleaned us-
ing clear, warm water.
– Highly soiled spots should be
presoaked and the detergent solution
should soak 5 to 10 minutes.
– Always work from the light to the shade
(from the window to the door).
– Always work from the cleaned to the un-
cleaned surface.
– The more sensitive the surface (oriental
rugs, berbers, upholstery material) the
lower the cleaning solution concentra-
tion should be.
– Rugs with jute backing can shrink if too
much water is used and can bleed col-
ours.
– Brush high-fiber rugs in the direction of
the weave after cleaning (using a fiber
brush or a scrubber).
– Water-proofing the fabric using Care
Tex RM 762 after the wet cleaning pre-
vents a quick resoiling of the textile sur-
face.
– Do not step on cleaned surfaces until
they have dried and do not place furni-
ture on them to avoid pressure spots or
rust stains.
– When cleaning previously shampooed
carpets, foam will be generated in the
dirt water reservoir. In such a case add
Foam ex RM 761 to the dirt water reser-
voir.
If you require further information please re-
quest the product information sheet and the
DIN safety data sheet for the respective
cleaning agent.
 Switch off the spray and suction switch-
es.
 Shortly activate the lever on bender to
decrease the pressure.
 Separate bender from the spray/suction
hose.
 Remove the lid.
see Figure 7
 Insert the suction hose into the fresh
water reservoir.
 Press the suction switch to turn on the
suction turbine.
 Remove the lid.
 Empty the fresh water reservoir and
switch the appliance off.
see Figure 8
 Remove the dirt water reservoir from
the appliance and empty it.
Cleaning methods
Normal soiling
Strong soiling or stains
Cleaning tips
Detergent
Carpet and upholstery
cleaning
RM 760 pow-
der
RM 760 tabs
RM 764 liquid
Defoaming RM 760
Waterproofing carpets RM 762
Mite removal RM 765 Mitex
Shutting down
Empty the fresh water reservoir
12 EN

Kärcher Puzzi 8/1 C Specifications

General

Type	Drum vacuum
Cleaning type	Wet
Dust capacity	- L
Product color	Black, Grey, Yellow
Dust container type	Bagless
Cord length	7.5 m
Carrying handle(s)	Yes
Maximum area covered	18 m²
Clean water tank capacity	8 L
Dirty water tank capacity	7 L
Airflow	61 l/s
Proper use	Professional
Noise level	- dB
Cleaning surfaces	Carpet, Hard floor
Vacuum air filtering	Water
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Maximum input power	1200 W
Annual energy consumption	- kWh

Weight and Dimensions

Depth	530 mm
Width	330 mm
Height	440 mm
Weight	9800 g
