Kärcher Puzzi 8/1 C Instruction Manual

– 4
 Connect the bender (with suction pipe
and nozzle) to the suction hose.
 Connect the coupling of the fresh water
hose to the bender and lock into place.
see Figure 9
 Fill approx. 2 litres of fresh water into
the fresh water reservoir.
Do not add any detergents.
see Figure 10
 Place nozzle into the dirt water reser-
voir.
 Press the spray switch to turn on the de-
tergent pump.
 Activate lever on bender and flush the
appliance for appr. 1 to 2 minutes.
 Turn off the appliance.
 Disconnect the mains plug from the
socket.
see Figure 11
 Remove the dirt water reservoir from
the appliance and empty it.
 Clean the external surfaces of the appli-
ance.
 Coil power cable around the carrying
handle and the lid (see overview on title
page).
Caution
Risk of injury and damage! Observe the
weight of the appliance when you transport
it.
see Figure 12
 For transport, place suction pipe on the
carrying handle and attach spray/suc-
tion hose to hook.
 When transporting in vehicles, secure
the appliance according to the guide-
lines from slipping and tipping over.
Caution
Risk of injury and damage! Note the weight
of the appliance in case of storage.
This appliance must only be stored in inte-
rior rooms.
 Danger
Danger of injury by electric shock.
First pull out the plug from the mains before
carrying out any tasks on the machine.
 Check high power cable, extension ca-
bles and hoses for damage every time
before use.
 Remove all water from the appliance
prior to longer periods of non-use to
avoid offensive odours.
 Clean the sieve in the fresh water reser-
voir and the lint trap next to the dirt wa-
ter reservoir regularly.
 Danger
Danger of injury by electric shock.
First pull out the plug from the mains before
carrying out any tasks on the machine.
Get the electrical components checked and
repaired only by authorised customer serv-
ice persons.
Contact an authorised customer service
person in case of problems not mentioned
in this chapter or if you are in doubt or when
you have been explicitly asked to do so.
 Fill up fresh water reservoir.
 Check couplings on the fresh water
hose for proper connection.
 Detach nozzle attachment and remove,
clean or replace nozzle.
 Clean the sieve in the fresh water reser-
voir.
 Detergent pump defective, contact Cus-
tomer Service.
 Clean nozzle mouthpiece.
 Check the correct positioning of the lid.
 Clean seal on lid and surface on the ap-
pliance.
Cleaning the device
Transport
Storage
Maintenance and care
Troubleshooting
No water exiting from nozzle
Spray stream one-sided
Insufficient vacuum performance
13EN

Kärcher Puzzi 8/1 C Specifications

General

Type	Drum vacuum
Cleaning type	Wet
Dust capacity	- L
Product color	Black, Grey, Yellow
Dust container type	Bagless
Cord length	7.5 m
Carrying handle(s)	Yes
Maximum area covered	18 m²
Clean water tank capacity	8 L
Dirty water tank capacity	7 L
Airflow	61 l/s
Proper use	Professional
Noise level	- dB
Cleaning surfaces	Carpet, Hard floor
Vacuum air filtering	Water
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Maximum input power	1200 W
Annual energy consumption	- kWh

Weight and Dimensions

Depth	530 mm
Width	330 mm
Height	440 mm
Weight	9800 g
