36
Seat Depth = 19"(Flexx Tall only)
Align the axle plate with one of the three adjustment holes. There are four
positions possible：(See Figure 5.3)
(1) Factory Setting is Standard position "D". For better stability, please
set it as Passive position "E" or "F".
(2) Active position with better handling is "B or C".
See Figure 5.3
I
Axle plate at E or F position= Active position.
II
Axle plate at D position= Standard position. (Factory Setting)
III
Axle plate at E position= Medium position.
IV
Axle plate at F position= Passive position.
WARNING:
● When the axle plate is set as Active position (E or F), anti-tippers
MUST be equipped to your wheelchair for safety reason.
