37
Seat Depth = 20”
Align the axle plate with one of the four adjustment holes. There are four
positions possible：(See Figure 5.4)
(1) Factory Setting is Standard position “E.” For better stability,
please set it as Passive position “F.
(2) Active position with better handling is “C or D”.
See Figure 5.4
.I
Axle plate at C or D position= Active position.
II
Axle plate at E position= Standard position. (Factory Setting).
III
Axle plate at F position= Passive position.
WARNING:
● When the axle plate is set as Active position (C or D), anti-tippers MUST
be equipped to your wheelchair for safety reason.
